Specifications
|
Model Name |
AMG-10IPAM02T1 |
|
Screen Size |
10.1" |
|
Display Resolution (pixel) |
1024x600 |
|
Contrast Ratio |
500:1 |
|
Aspect Ratio |
16:9 |
|
Touch screen(optional) |
4-Wire Resistive Touch(5-Wire for Optional) |
|
Brightness (CD/㎡) |
250/450nits |
|
Backlight |
LED |
|
Viewing Angles (CR=10) |
140Hx90V |
|
Power Consumption |
≤8W |
|
Dimension(VxHxT) |
255x150x236(stretching) |
|
Touch Interface |
USB (RS232 for Optional) |
|
Input Voltage |
DC12V±15% |
|
HDMI Format |
480i,480p,576i,576p,720p,1080i,1080p(50/60Hz) |
|
Operating Systems Support |
Windows 7 |
|
Operating Temperature |
-20~50℃ |
|
Storage Temperature |
-30~65℃ |
|
Relative Humidity |
5(%RH)~90(%RH) |
