Specifications
|
Model Name |
AMG-10IPPCX1T1 |
|
Screen Size |
10.4" |
|
Active Display Area (mm) |
210.4(H)x157.8(V) |
|
Pixel Pitch (mm) |
0.0685(H)x0.2055(V) |
|
Display Mode |
Normally black |
|
Display Resolution (pixel) |
1024X768 |
|
Contrast Ratio |
1200:1 |
|
Display Color |
16.2M colors |
|
Brightness (CD/㎡) |
350 |
|
Backlight |
LED |
|
Viewing Angles (CR =10) |
176 (H); 176 (V) |
|
Response Time(Typ.Tr+Tf) |
25ms |
|
Signal Connector |
VGA/DVI |
|
Power Consumption |
DC 12V |
|
Dimension(VxHxT) |
306.6x230.1x57 |
|
Operating Temperature |
-20~70℃ |
|
Storage Temperature |
-20~70℃ |
|
Relative Humidity |
5(%RH)~90(%RH) |
