Specifications
|
Processor System |
CPU |
Intel i5-2410M 2.30 GHz |
|
Memory |
DDR3 1333 4GB | |
| HDD |
HDD 320G 5400RPM. 2.5 SATA |
|
|
CD/DVD-ROM/RW |
NA |
|
|
PS/2 port |
PS/2 mouse and Keyboard port |
|
|
VGA port |
1xVGA port |
|
|
DVI port |
1xDVI port | |
| HDMI port |
1xHDMI port |
|
|
COM ports |
Default 1xCOM (Optional x 2 COM) |
|
|
USB 2.0 ports |
Default 4x2.0 USB (2 x USB 3.0) | |
|
eSATA ports |
1x eSATA |
|
|
Ethernet ports |
1x10/100/1000BASE-T Gigabit Ethernet | |
|
Audio |
Mic-in,Line-in , Line-out |
|
|
LCD Display |
Display Size |
15 |
|
Active Display Area(mm) |
304.128(H)x228.096(V) | |
| Max Resolution |
1024x768 |
|
|
Support Color |
16.2M/262K |
|
|
Luminance(CD/㎡) |
400 |
|
|
Contrast Ratio |
700:1 |
|
|
Pixel Pitch (mm) |
0.297x0.297 |
|
|
Display Mode |
Normally White | |
|
Viewing Angle(CR=10) |
160(H);140(V) |
|
|
Touch screen(optional) |
Type |
Resistive Touchscreen |
|
Power supply |
Use connector |
4pin USB2.0 |
|
Input Voltage |
AC 90-264V 4A 47~63Hz |
|
|
Output Rating |
60W(max) |
|
|
Output Voltage |
+12V @5A; |
|
|
Relative Humidity |
Dimension(VxHxT) |
410.4x317.4x83 |
|
Operating Temperature |
-30~80℃ |
|
|
Storage Temperature |
-30~80℃ |
|
|
Relative Humidity |
5(%RH)~90(%RH) |
