Specifications
|
Processor System |
CPU |
A20 1GHz Dual-core |
|
ROM |
4GB | |
| RAM |
1GB |
|
| OS |
Android 4.0.3 |
|
|
HDMI port |
1xHDMI |
|
|
USB ports |
2xUSB 2.0 |
|
|
Ethernet |
1x10/100/1000BASE-T Gigabit Ethernet |
|
|
CVBS/Audio |
CVBS IN/Left And Right Channels |
|
|
SD Card Expansion |
Maximum Storage Expansion:32GB |
|
|
LCD Display |
Screen Size |
12.1" |
|
Active Display Area(mm) |
246(H)x184.5(V) | |
|
Max Resolution |
800x600 |
|
|
Support Color |
16.2M/262K |
|
|
Brightness(CD/㎡) |
450 | |
| Backlight |
LED |
|
|
Contrast Ratio |
700:1 |
|
|
Pixel Pitch(mm) |
0.3075x0.3075 |
|
|
Viewing Angles(CR=10) |
160(H);140(V) |
|
|
Response Time(Typ.Tr+Tf) |
35ms |
|
| Type |
Type |
PCT Touch(10 Points) |
|
Power supply |
Use connector |
4pin USB2.0 |
|
Input Voltage |
AC 90-264V 4A 47～63Hz |
|
|
Output Rating |
60W(max) |
|
|
Output Voltage |
+12V @5A; |
|
|
Dimension(VxHxT) |
379x284x55 |
|
|
Temperature Range |
Operating Temperature |
-30~80℃ |
|
Storage Temperature |
-30~80℃ |
|
|
Relative Humidity |
5(%RH)~90(%RH) |
