Specifications
|
Model Name |
AMG-08OPNC02N1 |
|
Screen Size |
8.4" |
|
Active Display Area (mm) |
170.4(H) x127.8(V) |
|
Pixel Pitch (mm) |
0.213(H)x0.213(V) |
|
Display Mode |
Normally white |
|
Display Resolution (pixel) |
800x600 |
|
Contrast Ratio |
600:1 |
|
Display Color |
16.2M/262k colors |
|
Brightness (CD/㎡) |
250 |
|
Backlight |
LED |
|
Viewing Angles (CR =10) |
160 (H); 140 (V) |
|
Response Time(Typ.Tr+Tf) |
35ms |
|
Signal Connector |
VGA |
|
Power Consumption |
DC 12V |
|
Dimension(VxHxT) |
238X180X33.5 |
|
Operating Temperature |
-20~70℃ |
|
Storage Temperature |
-20~70℃ |
|
Relative Humidity |
5(%RH)~90(%RH) |
