Specifications
|
型号 Model Name |
AMG-17OPMD01N1 |
|
屏幕尺寸 Screen Size |
17" |
|
显示区域 Active Display Area (mm) |
337.920 (H) x 270.336 (V) |
|
像素点 Pixel Pitch (mm) |
0.264(H)x0.264(V) |
|
显示模式 Display Mode |
Normally white |
|
分辨率 Display Resolution (pixel) |
1280x1024 |
|
对比度 Contrast Ratio |
800:1 |
|
颜色像素 Display Color |
16.7M colors |
|
亮度 Brightness (CD/㎡) |
300 |
|
背光 Backlight |
CCFL/LED |
|
可视角度 Viewing Angles (CR =10) |
160 (H); 160 (V) |
|
响应时间 Response Time(Typ.Tr+Tf) |
5ms |
|
信号接口 Signal Connector |
VGA/DVI |
|
电源接口 Power Consumption |
DC 12V |
|
外观尺寸 Dimension(VxHxT) |
387.6x313.1x45.3 |
|
工作温度 Operating Temperature |
0~50℃ |
|
储存温度 Storage Temperature |
-20~60℃ |
|
相对湿度 Relative Humidity |
5(%RH)~90(%RH) |
